Handles TL.W2
Material and surface:
Tube ø30x1,5 mm of stainless steel, material no. 1.4301; fine ground. Handle shanks of extruded aluminium AlMgSi 0.5; natural colour anodized with dull bright finish. Shank insert of polyamide PA6 with a fixed disc of stainless steel, material no. 1.4305; fine lathed.
Stress resistance:
min. 1000 N.
|
Unit of measure
|
||
|---|---|---|
| Fitting type | ||
| A | L |
attachment from behind
Order-No. |
| A | L |
attachment from behind
Order-No. |
|---|---|---|
| A 200 | L 250 |
attachment from behind
Order-No. TL.W2-30.R200.37 3D+CAD |
| A 250 | L 300 |
attachment from behind
Order-No. TL.W2-30.R250.37 3D+CAD |
| A 300 | L 350 |
attachment from behind
Order-No. TL.W2-30.R300.37 3D+CAD |
| A 350 | L 400 |
attachment from behind
Order-No. TL.W2-30.R350.37 3D+CAD |
| A 400 | L 450 |
attachment from behind
Order-No. TL.W2-30.R400.37 3D+CAD |
| A 500 | L 550 |
attachment from behind
Order-No. TL.W2-30.R500.37 3D+CAD |
| A 600 | L 650 |
attachment from behind
Order-No. TL.W2-30.R600.37 3D+CAD |
| Single parts | Order-No. |
|---|
