Design Advantages:
Simple and stable mounting with threaded brass bush. Robust formation of the tray interior, no slip of fingers in both movement directions. Suitable for a panel thickness between 1-5 mm.
Material and surface:
Polyamide PA 6, glass ball reinforcement, fine structure in visible surface, in 4 different colour versions.
Mounting:
The front section is first set into the recess in the housing panel. The rear section is now pushed onto the front section which projects into the housing interior. The handle is than fixed in position with the aid of 4 screws.
Scope of supply:
Includes galvanised oval head screws with cross recess DIN 7985.
