Handles EB

For machines and all technical areas where maximum loadbearing capacity is required.

Material and surface:
Round stainless steel; material no. 1.4404; ground and brushed with a half-matt finish.

Scope of delivery:
Handle versions EB-15.R and EB-20.R including hexagon screws DIN 933 and washers DIN 125; Version EB-20.F including mounting adapter, nuts DIN 934 and washers DIN 125 made of stainless steel.

Note:
Other dimensions on request.

Stress resistance:
min. 1000 N.

show more show less

Version EB-15.R

Unit of measure
Fitting type A Order-No.
Fitting type A Order-No.
Fitting type attachment from behind A 150 Order-No. EB-15.R150.33 3D+CAD
Fitting type attachment from behind A 200 Order-No. EB-15.R200.33 3D+CAD
Fitting type attachment from behind A 250 Order-No. EB-15.R250.33 3D+CAD

Version EB-20.F

Technical drawing of stainless steel handle EB-20.F with sectional views of mounting components including screws, nuts, washers, and adapter
Unit of measure
Fitting type A Order-No.
Fitting type A Order-No.
Fitting type attachment from the front A 200 Order-No. EB-20.F200.33 3D+CAD
Fitting type attachment from the front A 250 Order-No. EB-20.F250.33 3D+CAD
Fitting type attachment from the front A 300 Order-No. EB-20.F300.33 3D+CAD

Version EB-20.R

Technical line drawing of EB-20.R stainless steel handle including cross-section and front view showing mounting details
Unit of measure
Fitting type A Order-No.
Fitting type A Order-No.
Fitting type attachment from behind A 200 Order-No. EB-20.R200.33 3D+CAD
Fitting type attachment from behind A 250 Order-No. EB-20.R250.33 3D+CAD
Fitting type attachment from behind A 300 Order-No. EB-20.R300.33 3D+CAD
